Wire Tong Block Clamp

Description

The wire tong blocks clamp is used as a fixing point for straining the wire tong using a rope block, connected to the eye-ring of the blocks clamp. Such assembly aligns the straining loads with the wire tong, helping to lift heavy conductors back to their original position.

The blocks clamp is manufactured in aluminum alloy. The eye-ring, tightening threaded bolt and wing-nut are manufactured in cooper alloy.

The inner walls of the clamp are covered with a stainless steel layer, in order to protect the surface of the pole from mechanical damages.

The clamp is composed of two parts which open up to fix onto the pole, by tightening the wing nut, located on one of the sides of the clamp.

Spring action wing-nut and threaded bolt assembly makes the clamp operation easier, quicker and safer.

Wire Tong Block Clamp

Cat. No.

Diam.
(in)

Work Load (lb)

Approx. Weight (lb)

 RM4743

1.5"

1235

2.43

 RM4743-1

2.0"

1235

2.65

 RM4743-2

2.5"

1235

2.87
